Processing

HiDef Plasma

Our in-house high definition plasma cutting capabilities offer a cost-effective, customizable solution for your metal processing needs.

Features And Benefits

Tolerances of +/- .0625 are possible

Superior cut on carbon, aluminum and stainless steel plate

Compatible with customer-provided DXF files

HiDef Plasma

Boyd Metals has taken quality to the next level with the addition of in-house high definition plasma cutting capabilities.

The features and benefits of our high definition equipment include:

  • All high definition plasma cutting equipment at Boyd Metals is CNC controlled in order to provide the most consistent, closest tolerance parts possible.
  • High definition plasma provides even tighter tolerances. Tolerances of +/- .0625 are possible.
  • High Definition plasma provides a superior quality cut on carbon, aluminum and stainless steel plate.
  • High Definition plasma’s increased cutting speeds reduce turnaround time.
  • High Definition plasma produces less slag, resulting in minimal, if any, clean up time.
  • Thickness capacity up to 1″.
  • Table capacities of up of 120″ wide and 480″ long.
  • Each high definition plasma-burning center has over 250 pre-programmed shapes. Other shapes are programmed in-house using the latest Auto-Cad technology.
  • Boyd Metals high definition plasma burning centers are compatible with customer provided DXF files. Using your files improves turnaround time, minimizes the opportunity for programming error and provides further cost savings to you, the customer.
  • Nesting software provides for efficient use of materials, resulting in minimal scrap.
